Split Tensile Test Device NL 4012 X / 002
The NL 4012 X / 002 Split Tensile Test Device is a robust and reliable instrument designed for testing the tensile strength of concrete cube specimens with sizes of 100mm and 150mm. It is widely used in construction laboratories, quality control departments, and research institutions to assess the tensile properties of concrete in accordance with various international standards, including ASTM C496 and EN 12390-6.
Downloads:
-
Warranty 1 year
-
Free 14-Day returns
Description
Standard: BS EN 12390-6, ASTM 496
Used to perform tests on concrete cube specimens for 100mm and 150mm cubes. It consist of top compression plunger and specimens. Holder Jig supplied WITHOUT packing strips. Need to order separately.
Key features of the NL 4012 X / 002 Split Tensile Test Device:
- High accuracy and repeatability: The device is equipped with a precision load frame and displacement transducer to ensure accurate and repeatable test results.
- Easy to operate: The simple design of the device makes it easy to set up and operate, even for inexperienced users.
- Versatile: The device can be used to test concrete cubes of different sizes with the addition of optional accessories.
- Durable construction: The device is made from high-quality materials and is built to last.
Specification
Overview
| Weight | 14 kg |
|---|---|
| Dimensions | 21 × 20.5 × 31 cm |
| Brand |
Nl Test |
| Model number |
NL 4012 X / 002 |
| Specimen Size (mm) |
100 x 150 mm Cube |
|---|
